Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System

    Buy cheap Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System from wholesalers

    Buy cheap Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System from wholesalers
    • Buy cheap Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System from wholesalers
    • Buy cheap Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System from wholesalers

    Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System

    Ask Lasest Price
    Price : negotiated
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    Delivery Time : negotiated
    • Product Details
    • Company Profile

    Home Photovoltaic Energy Storage Systems 2Kw 3Kw 5Kw All In One Solar System

    All In One Photovoltaic Solar Energy Storage System 2Kw 3Kw 5Kw Complete Solar System For Home Off Grid Full Set

    Product details

    What's Included:
    340W Mono Solar Panel
    2 Piece
    4 Piece
    6 Piece
    9 Piece
    12 Piece
    MC4 Y Branch
    1 Pair
    1 Pair
    2 Pair
    /
    /
    Combiner Box
    /
    /
    /
    3 in 1 out
    4 in 1 out
    Off Grid Inverter
    1KW
    2KW
    3KW
    4KW
    5KW
    12V 200AH Battery
    1 Piece
    2 Piece
    4 Piece
    4 Piece
    8 Piece
    DC Cable
    100 Meters
    100 Meters
    200 Meters
    200 Meters
    200 Meters
    MC4 Connector
    4 Pair
    4 Pair
    6 Pair
    6 Pair
    8 Pair
    Mounting System
    Standards Pitched Roof ( Customized Optional)

    Off Grid System Configuration
    Mono Solar Panels
    Peak Power Watts: 340W (SP340M-60H)
    Maximum Power Voltage: 34.2V
    Maximum Power Current: 9.94A
    Open Circuit Voltage: 41.1V
    Short Circuit Current: 10.6A
    Dimensions:1698×1004×35 mm (66.85×39.53×1.38 inches)
    Weight:18.7 kg (40.8 lb)

    Off Grid Inverter
    The Off Grid Inverter is Integrated with a MPPT Solar Charger Controller,a High Frequency Pure Sine Wave Inverter and a UPS
    Fuction Module in One Machine.Remote Monitoring is Available by Using Wifi Monitoring Kit.

    PV Mounting System
    Mounting Rail & Rail Splice Kit: AI6005 & SUS304 Bolt.
    Mid & End Clamps: 35,40,45,50mm
    L Foot Asphalt Shingle Moount & Hanger Bolt Optional
    Cable Clip & Tie Optional
    Ground Clip & Lugs Optional

    Lead Acid GEL Battery
    Capacity(kWh): 2.4
    Nominal Voltage(Vdc): 12
    Nominal Capacity(AH): 200
    Depth of Discharge: 70%

    DC & AC Disconnect Switch
    IP Rating: IP66
    Rated Voltage: 600VDC/1000VDC
    Connection Type: M20,M25,MC4
    Rated Current: 16A,32A

    DC Cable & MC4 Connector & Y Branch
    Cross Section: 4mm2, 6mm2 Optional
    Rated Voltage:600VDC(UL)/1000VDC(TUV)
    Rated Current: 55A,70A
    Colors: Black For STD, Red Optional.
    Lifetime:≤25 Years

    PV Tools
    Wire Cable Cutter & Stripper,
    MC3 MC4 Crimper
    MC4 Connectors Assembly
    Disassembly Tool

    1. who are we?

    We are based in Guangdong, China,sell to Domestic Market(55.00%),Western Europe(21.00%),North America(14.00%),Eastern Asia(6.00%),South Asia(1.00%),Eastern Europe(1.00%),Mid East(1.00%),Southeast Asia(1.00%),South America(0.00%),Oceania(0.00%),Southern Europe(0.00%),Central America(0.00%),Northern Europe(0.00%),Africa(0.00%). There are total about 100+ people in our office.


    2. how can we guarantee quality?

    Always a pre-production sample before mass production;

    Always final Inspection before shipment;


    3. what services can we provide?

    Accepted Delivery Terms: FOB,CIF,EXW;

    Accepted Payment Currency:USD,EUR,HKD,CNY;

    Accepted Payment Type: T/T,L/C,PayPal,Western Union,Cash,Escrow;

    Language Spoken:English,Chinese,Russian


    4. MQQ: 1 piece
