Solar Energy Storage System All In One Energy Storage Battery 24V 48V 100Ah 200Ah 5KWh 10KWh Solar Energy Systems

Ask Lasest Price
Price :	negotiated
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :	negotiated

Add to Cart

Product Details
Company Profile

Solar Energy Storage System All In One Energy Storage Battery 24V 48V 100Ah 200Ah 5KWh 10KWh Solar Energy Systems

Product parameters

Specifications
Model	PMD-5kWh	PMD-10kWh	PMD-20kWh	PMD-30kWh
Dimension (WDH)(mm)	570400390	570400550	570400870	5704001190
Weight	70kg	120kg	220kg	320kg
Battery Parameters
Number of Battery Packs in Parallel	1 x 100Ah	2 x 100Ah	4 x 100Ah	6 x 100Ah
Rated Capacity (kWh)	5kWh	10kWh	20kWh	30kWh
Rated Voltage	51.2V
Rated Charge/Discharge C-rate	0.5C
DoD	90%
Life Cycle	6000 times(25℃, 80% State of Charge)
Communication Method	RS485/CAN/RS232
Certification	cell: UL1973, IEC62619, IEC62133. battery pack: UL1973, MSDS, UN38.3, CE.
Inverter Parameters
Rated Input Voltage/Input Range.	110 / 220V AC / (90V AC-240V AC)±2%
Frequency	50Hz-60Hz (Auto-detection)
Efficiency	＞95%
Rated Output Voltage	110V AC/220V AC
Rated Output Power	5000W
Peak Power	10000VA
Maximum Bypass Overload Current	63A
Rated Battery Input Voltage	Minimum Startup Voltage 44V

Grid Input Parameters
Maximum Charging Current	40A
Charging Voltage Range	40-60V DC
Circuit Breaker Specifications	63A
Solar Panel Input Parameters
Maximum PV Open Circuit Voltage	500V DC
PV Operating Voltage Range	120-500V DC
MPPT Voltage Range	120-450V DC
Maximum PV Input Power	5000W
Solar Charging Current (Settable)	0-80A (Adjustable)
AC Output Parameters
Output Voltage Waveform	Pure Sine Wave
Rated Output Voltage (V)	110/220V AC
Rated Output Power (W)	5000(4100/4300/4500)
Operating Environment
Operating Temperature Range	0℃~55℃
Operating Humidity Range	5％~95％
Noise	≤60dB
Cooling System	Natural Cooling (No Condensation)

Solar Energy Storage System All In One Energy Storage Battery 24V 48V 100Ah 200Ah 5KWh 10KWh Solar Energy Systems

Company Profile

Guangzhou Pei Mengdan new energy Technology Co., LTD is a high-tech enterprise specializingin research, development, production and sales of high-performance lithium ironphosphate batteries and polymer lithium batteries. lt is committed to providingcustomers with safe and durable battery products such as household energy storage, outdoor power supply, etc.

Solar Energy Storage System All In One Energy Storage Battery 24V 48V 100Ah 200Ah 5KWh 10KWh Solar Energy Systems

More features

Long life and safety	Vertical industry integration ensures more than 6000 cycles with 80% DoD
Intelligent	Each battery with an independent BMS system manages power output smartly and effectively
Easy to install and use	Small size, minimizing installation time and cost Compact and stylish design suitable for your sweet home environment

Solar Energy Storage System All In One Energy Storage Battery 24V 48V 100Ah 200Ah 5KWh 10KWh Solar Energy Systems

FAQ

Q1: MOQ

A: MOQ form our company is required 1 unit.

Q2: What's your main products?
A: Main product is lithium battery, solar inverter,etc.

Q3: I need this product and wanna a system for family/industrial/commerical using,can you help me?
A: Yes,we have professional technology team ,they can design solar power system in accordance with customers' special requirements.

Q4: How long is your delivery time?
A: For air shipment, it usually take 3-5 days. For sea shipment, it usually take 15 ~ 25 days.

Q5: How about your after sales service?
A: Our quality warranty for 5 years,any parts will be shipped for free during warranty period.
