Most Popular All-In-One Hybrid Energy Storage System 5kW 10kW Residential ESS

Ask Lasest Price
Price :	negotiated
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :	negotiated

Add to Cart

Product Details
Company Profile

Most Popular All-In-One Hybrid Energy Storage System 5kW 10kW Residential ESS

Product parameters

Model No	PMD-48100	PMD-48200	PMD-51100	PMD-51140	PMD-51200
Batteries materials	Lithium iron phosphate
Nominal voltage	48V	48V	51.2V	51.2V	51.2V
Nominal capacity	100Ah	200Ah	100Ah	140Ah	200Ah
Size(mm)	471375147	590375245	67054090	1095420150	685470350
Weight	42kg	82kg	50kg	73kg	85kg
Color	Optional
Parallel support	Parallel terminals are supported
Output port mode	terminal
Charging way	CC/CP/VP
Charging current	0.2C(standard)
Maximum charging current	Max0.5C @25℃
Discharge way	CC/CP/VP
Discharge current	0.5C
Charge cut-off voltage	54.8V/CELL
Maximum discharge current	Max1.2C @25℃
Discharge cut-off voltage	36.4V	36.4V	44.8V	44.8V	44.8V
According to	LCD
Communication interface	RS485/RS232/CAN
Charging operating temperature	charging:0~+50℃
Discharge operating temperature	discharge:-20~+55℃
The quality assurance period	5 years
Applicable scope	hospital, bank data center, base frame type home,enterprise energy storagebackup power supply, wind complementary system,office, military, base station and other uninterrupted energy storage power supply.

Most Popular All-In-One Hybrid Energy Storage System 5kW 10kW Residential ESS

※ Scalable Configuration

Modular design: one storage system can support 2 to 5 battery units. Systems can be connected in parallel

※High Safety

System design based on LFP batteries, which have greater thermal stability.

※Quick Installation

Fast-plug connector design to save in- stallation time and cost.

※Long Service Life

More than 6000 cycles at recommended condition.

※IP54 Rating

IP54 water- and dust-proof, supports both indoor and outdoor installation.

※High Usage

Battery usable energy up to 95%.

Company Profile

Guangzhou Pei Mengdan new energy Technology Co., LTD is a professional battery manufacturer, PMD manufactures and sells environmentally friendly Sealed Lead Acid (SLA) and Lithium batteries. PMD introduces and develops advanced technology, and adopts the world's most advanced production equipment and testing measures to ensure long product life, high energy density, and environmental protection features such as cadmium-free, leading the domestic counterparts.

Most Popular All-In-One Hybrid Energy Storage System 5kW 10kW Residential ESS

Application

Most Popular All-In-One Hybrid Energy Storage System 5kW 10kW Residential ESS

FAQ

Q1. Are you a manufacturer?
A. Yes, sir, we have our own factory, the price is factory direct.

Q2. Can I have a sample order?
A. Yes,welcome sample order to test and check quality.

Q3. What about the lead time?
A. Sample 5-10 days, mass production time 3-5 weeks depending on order quantity.

Q4. Do you have any MOQ limit?
A. Yes, but low MOQ, 1~10pcs sample order is available.

Q6. How to proceed with an order?
A. 1st, please let us know your requirements or application. 2nd, We offer our quotation. 3rd, customer confirms the samples and make a deposit for formal order. 4th, We produce your order.

Q7. How can I do if I need more help for the order?

You can chat our sales online or send inquiry email,we will respond you ASAP.
