Commercial Hybrid Grid Solar Pv System Solar Kit Home Energy Storage For Power Systems
Product parameters
| | 1KW System | | 2KW System |
| Solar Panel | 450WP×2pcs | Solar Panel | 450WP×4pcs |
| Solar Generator | MPPT 1KW/24V/60A | Solar Generator | MPPT 2KW/48V/60A |
| Gel Battery | 100AH/12V×2Pcs | Gel Battery | 100AH/12V×4pcs |
| Cable | 4mm2×40m+10mm2×2m | Cable | 4mm2×40m+10mm2×2m |
| PV Bracket | 1KW Matched | PV Bracket | 2KW Matched |
| Battery Rack | Matched | Battery Rack | Matched |
| | | Combiner | MC4 2 to 1 2pairs |
| Performance Average production power daily 4.6kWh Rated output power: 1KW | Pure sine wave: 110V//220V 50Hz/60Hz In case of
over-discharge, system can switch to grid power automatically. | Average production power daily 10.5kWh Rated output power: 2KW | Output Power: 110V//220V 50Hz/60Hz In case of over-discharge, system can switch to grid power automatically. |
| | 3KW System | | 4KW System |
| Solar Panel | 540WP×4pcs | Solar Panel | 540WP×6pcs |
| Solar Generator | MPPT 3KW/48V/70A | Solar Generator | MPPT 4KW/48V/100A |
| Gel Battery | 150AH/12V×4Pcs | Gel Battery | 200AH/12V×4pcs |
| Cable | 4mm2×40m+6mm2×6m | Cable | 4mm2×40m+12mm2×6m |
| PV Bracket | 3KW Matched | PV Bracket | 4KW Matched |
| Battery Rack | Matched | Battery Rack | Matched |
| | | PV Box | 4KW Matched |
| Average production power daily 15.5kWh Rated output power: 3KW | Pure sine wave: 110V//220V 50Hz/60Hz In case of over-discharge, system can switch to grid power automatically. | Average production power daily 19.6kWh Rated output power: 4KW | Pure sine wave: 110V//220V 50Hz/60Hz In case of over-discharge, system can switch to grid power automatically. |
| | 5KW System | | 10KW System |
| Solar Panel | 540WP×8pcs | Solar Panel | 540WP×16Pcs |
| Solar Generator | 5KW/48VV/120A | Solar Generator | 10KW/96V/120A |
| Gel Battery | 200AH/12V×4pcs | Gel Battery | 200AH/12V×8pcs |
| Cable | 4mm2×50m+14mm2×10m | Cable | 4mm2×80m+14mm2×10m |
| PV Bracket | 5KW Matched | PV Bracket | 10KW Matched |
| Battery Rack | Matched | Battery Rack | Matched |
| PV Box | 5KW 1set | PV Box | 10KW 1set |
| Average production power daily 24kWh Rated output power: 5KW | Pure sine wave: 110V/220V/50Hz/60Hz In case of over-discharge, system can switch to grid power automatically. | Average production power daily 49kWh
Rated output power: 10KW | Pure sine wave: 110V/220V/380V50Hz/60Hz In case of over-discharge, system can switch to grid power automatically. |
Solar panels
1, High efficiency A Grade mono cells, 300W
2, 21% conversion efficiency
3, Anti-reflection tempered glass
4, Anodic aluminium-alloy frame
5, MC4 junction box
Inverter 10KW:
1, Double CPU intelligent control
2, Settable the mains mode
3, Controlled by intelligent fan
4, Pure sine wave AC output
5, LCD display
6, Automatic protection
7, RS232 communication interface design
Solar charge controller:
1, MCU intelligent control
2, LCD+LED display mode
3, Kinds of battery protect data setting
4, Complete protect
5, History record and password protect function
6, Time display function
1. why should you buy from us not from other suppliers?
We have a complete automatic energy storage system production line. Grade A battery cells. Intelligent
BMS system. UL certified wiring harness.
2. Does the shipping way to our country include tax?
It depends on the country and the shipping way you choose.
3. Is this product safe?
Passed the overcharge, over discharge, over temperature, short circuit, acupuncture and other safety tests,
no fire, no explosion at any circumstance.
4. How to confirm the high quality of the product you sent me?
Our batteries are all grade A, No matter how many you order, we will test each product before sending out.
5. Is it OK to print my logo on the product?
Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
